Raw Material : PP GF30
Weight : 176.5 g
Shrinkage: 0.6%
Cavity Number : 1+1
Gate: Moldmasters HOT RUNNER
Surface Finish: smooth
Cavity Steel: P20HH (HRC28-32)
Core Steel: P20HH (HRC28-32)
Moldbase: S50C
Part size: 222.08 X 267.78 X 228.79MM
Mold size: 932*700*850MM
Mold weight: 3690KG
Use strip block
Moldflow analysis:
filling study
Weldline:
Air Traps:
Sink Marks:
Cooling with water:
Cooling with water:
X deflection:
Y deflection:
Z deflection:
EDM process:
CNC process:
